Insulator Side Tie
★PVC plastic line ties / top ties are intended for use with covered conductors and vertically-mounted tie top insulators on crossarms or pole-top-mounted insulators. Line angles of up to 15°can be accommodated when used with any plastic covered conductor.

  • Insulator Side Tie

    We use the all new raw material, not recycling material to make the product. so it has the following advantages such as UV resistance, good tensile strength, impact strength and flexural strength etc. We can make them in black, white as well as grey at present.





  • Plastic single Side Tie

    Model Dia.of Insulator(mm)Dia.of applied Cable (mm)Material Single Side Tie
    HPDCB63-13726310.19-13.72Ordinary PVC
    HPDCB63-1372DSemiconductor PVC
    HPDCB63-20406316.5-20.4Ordinary PVC
    HPDCB63-2040DSemiconductor PVC
    HPDCB73-23377321.0-23.37Ordinary PVC
    HPDCB73-2337DSemiconductor PVC
    HPDCB73-27947323.39-27.94Ordinary PVC
    HPDCB73-2794DSemiconductor PVC

    Plastic double Side Tie

    Model Dia.of Insulator(mm)Dia.of applied Cable (mm)Material Double Side Tie
    HPDCB63-0970638.03-9.7Ordinary PVC
    HPDCB63-0970DSemiconductor PVC
    HPDCB63-13726310.19-13.72Ordinary PVC
    HPDCB63-1372DSemiconductor PVC
    HPDCB73-20407316.5-20.4Ordinary PVC
    HPDCB73-2040DSemiconductor PVC
    HPDCB73-23377321.0-23.37Ordinary PVC
    HPDCB73-2337DSemiconductor PVC
    HPDCB73-27947323.39-27.94Ordinary PVC
    HPDCB73-2794DSemiconductor PVC



  • Packaging: preformed guy grip according to the concrete product， Usually packed with wooden cases(as customer's requirements)

    Delivery: usually, it will take about two weeks for the order of 10000 sets for production

    Terms of Payment : By T/T
